* Please visit the product pages on our website for the most up-to-date product information
M INI -C ON -X ? F IELD I NSTALLABLE C ONNECTORS
Part Number to Order
X X XX-XXG-XXX
Connector Type:
6 - Cable End
Grommet Code –
Cable O.D. Range:
7 - Panel Mount
8 - Cable to Cable
Back Shell
11 -
15 -
.09 - .14 (2.3 - 3.5)
.15 - .17 (3.8 - 4.3)
Contact Size:
Style 3
18 -
21 -
.18 - .20 (4.6 - 5.1)
.21 - .23 (5.3 - 5.8)
2 - #20 (2-8 Contacts)
3 - #16 (2-5 Contacts)
Contact Style:
80 - Crimp (Supplied loose)
Back Shell
Style 5
13 -
16 -
19 -
22 -
.13 - .15 (3.3 - 3.8)
.16 - .18 (4.1 - 4.6)
.19 - .21 (4.8 - 5.3)
.22 - .25 (5.6 - 6.3)
81 -
82 -
91 -
92 -
P/C Tail .187" (4.7) (Supplied assembled)
Solder Cup (Supplied assembled)
P/C Tail .280" (7.1) (Supplied assembled)*
P/C Tail .335" (8.5) (Supplied assembled)*
Back Shell Style:
3 Weathertight grommet grip/
seal & (1) interfacial “O” ring.
3DC - Daisy chain grommet with 3
Number of Contacts:
2, 3, 4, 5, 6, 7 & 8
5
I.D.s. (.125, .188 & .250)
Long back shell with extended
grommet & cable grip. Use
with crimp or solder.
Type of Contact:
P - Pin
S - Socket
300 - Panel mount with hex nut &
gasket.
3ES - 300 with Epoxy
Contact Plating:
G - Gold over Nickel (Standard)
*Available in #20 size contact only.
Consult factory for optional threaded coupling.
Consult factory for your custom design cable assemblies and connectors. (See pages 3 & 26)
Contact Arrangements
Contact arrangements shown are wiring view of cable end pins/sockets.
Key/keyway shown for orientation only.
*Available in connector types: cable end socket, panel mount pin, and cable to cable pin styles only.
?
601 East Wildwood, Villa Park, Illinois 60181 ? Telephone (630) 834-7504 ? Fax (630) 834-8540 ? www.conxall.com
12
